View and Download Behringer CHROMATIC TUNER TU300 user manual online. Behringer TU300 Chromatic Pedal Tuners: User Guide. CHROMATIC TUNER. No matter what kind of tuning you prefer, the Behringer Chromatic Tuner TU300 can accommodate you! That's because this crucial stompbox gives you three guitar modes (regular, flat, double flat), three bass modes (regular, flat, double flat) and a chromatic setting.
CHROMATIC TUNER TU100
Thank you for showing your confidence in us by purchasing the BEHRINGER CHROMATIC TUNER
TU100. This compact guitar and bass tuner provides 7 different tuning modes. Thanks to its 7-segment
LED display and 11-point LED indicators, it provides great visibility, especially in dark environments.
1. CONTROLS
Top view
The ON/BATT LED illuminates when the tuner is activated. It also serves as a battery level indicator.
This LED meter indicates to what degree the instruments tone deviates from the reference tone.
These yellow arrow LEDs light up when the played note is below or above pitch. Both LEDs will
light up when the tones pitch is correct.
The 7-segment LED display indicates the string number (high E string: 1, B string: 2 etc.) of
the strummed string of your instrument, if the TU100 is operated in one of the guitar or bass
modes. In chromatic mode it displays the note name. Semitones are shown by the decimal point
LED (#) in the display.
Press the STREAM/CENT button to switch between the LED display modes (see chapter OPERATIONS).
Press the MODE button to select the tuning mode (see chapter OPERATIONS).
Use the footswitch to activate/deactivate the tuner.
Connect your guitar or bass to the 1/4' TS IN connector.
Connect your amp or another stompbox to the 1/4' TS OUT connector. When the tuner is activated
(footswitch pressed) the output is muted. This way, you can silently tune your guitar or bass.
The 1/4' TS BYPASS connector always sends a signal to your amp independently of the
footswitch position.
Use the DC IN connection at the right side of the unit to plug in a 9 V power supply (not included).
The BATTERY COMPARTMENT is located underneath the pedal cover. To install or replace the 9 V
battery, press the hinges with a ballpen and remove the pedal cover. Be careful not to scratch the unit.
+
The TU100 is powered as soon as you insert a plug into the INPUT. The battery is
disconnected when the plug is removed. For this reason, the TU100 has no on/off
switch. To extend battery life, always disconnect the INPUT when the unit is not in use.
The SERIAL NUMBER is located at the bottom.
2. OPERATION
Selecting the tuning mode: Select between 3 Guitar modes (Regular, Flat, Double Flat), 3 Bass
modes (Regular, Flat, Double Flat) and Chromatic mode.
'LVSOD
000f
0010
0011
0012
0013
000f
'LVSOD
000f
0010
0011
0012
0013
String
1
st
2
nd
3
rd
4
th
5
th
6
th
String
1
st
2
nd
3
rd
4
th
5
th
Regular
(
%
*
'
$
(
Regular
*
'
$
(
%
E
E
E
B
E
G
E
D
E
A
E
E
E
E
G
E
D
E
A
E
E
E
B
E
EE
D
A
Chromatic Tuner Instructions
F
C
G
D
EE
F
C
G
D
A
Guitar (left) and bass (right) tuning modes
Guitar modes:
s
Press the MODE button repeatedly until the GUITAR meter LED lights up. If you want to play
in flat or double flat mode, select b or bb guitar mode.
s
Pick a single string on your guitar. The string number closest to the pitch of the played tone will
be displayed. The meter LEDs
and the pitch indicators
will show the pitch deviation.
Bass modes:
s
Press the MODE button repeatedly until the BASS meter LED lights up. For flat or double flat
mode select b or bb bass mode.
s
Pick a single string on your bass. The string number closest to the pitch of the played tone will
be displayed. The meter LEDs
and the pitch indicators
will show the pitch deviation.
Behringer Chromatic Tuner Tu300
Chromatic mode: In chromatic mode the tuner automatically recognizes all tones and semitones and
Free Chromatic Tuner
indicates the note name in the LED display. Chromatic is the standard mode when powering up the TU100.
s
Cycle the MODE button to make the CHROMATIC LED light up.
s
Play a single note on your instrument. The note closest to the pitch of the played tone will be indicated.
s
Tune your instrument until the green 0 cent LED of the meter display
and the pitch indicators
light up.
